Sprinter Kit - Option 2


Product Code: PA-KITS-02
Availability: In Stock
Call for Pricing: (855) 881-1800
- +

Kit includes: 1 x Large Evaporator, 1 x Roof-Mount 2-Fan Condenser, TM16 Compressor - (engine bracket kit available if vehicle was not ordered with LBS kit), Booster Pump, Electric Water Valve, Hose, and all Required Fittings.

Option: Separate Floor Heater Available. Please call for information.

Large Evaporator:
  • 65,000 BTU
  • 18 amps @ 13.5 volts
  • 1600 CFM
  • Free Blowing Ceiling Mount Design
  • High Performance DCM Motors
  • Unique Drain Pan Design for Eliminating Condensation Issues
  • Evaporator Mounted Pressure Switches for Maximum Compressor Protection
  • Size: 8-1/2"H x 41-1/2"W x 15"D
  • Weight: 58 lbs
  • PART #: EV-5000
Roof-Mount 2-Fan Condenser:
  • 75,000 BTU
  • 23 amps @ 13.5 volts
  • 2460 CFM
  • 2-12" Sealed Spal Fans
  • 4 Row Aluminum Fin Coil with Internally Enhanced Copper Tubing and 16 Gauge Galvanized Endplates
  • Lightweight, Aluminum Frame
  • Low Profile, Aerodynamic ABS High Strength Cover
  • Size: 6"H x 36"W x 40"D
  • Weight: 41 lbs
  • PART #: RC-2000
Digital Controller Kit:
  • Available in Automatic or Manual Control Mode
  • Kit Includes: Digital Controller, 2 Relay Boards, Y Harness Adapter, Temperature Probe and Wiring Harness
  • Size: 4-1/2"W x 2-1/2"H x 1"D
  • Part #: PA-CON-200
